Full inverter modular design enables rapid, energy-efficient hot water delivery, continuously meeting the 24/7 demand of four-person households.
| Model | Unit | MGH056 | |
| Moderate Temp Heating Capacity (A20℃) | Heating Capacity | kW | 56 |
| Input Power | kW | 12.40 | |
| COP | – | 4.50 | |
| Nominal Heating Capacity (A7℃) | Heating Capacity | kW | 44 |
| Input Power | kW | 10.70 | |
| COP | – | 4.10 | |
| Low Temp Heating Capacity (A-7℃) | Heating Capacity | kW | 30 |
| Input Power | kW | 8.00 | |
| COP | – | 3.75 | |
| Water Output under diffenrent temp | 20/7/-7℃ | L/h | 1206/824/562 |
| Max Input Power | KW | 19.7 | |
| Max Input Current | A | 33.5 | |
| Power Supply | – | 380V/3N-/50Hz | |
| Heating Operating Ambient Temperature Range | ℃ | -35-45 | |
| Compressor | Type | – | DC Inverter Scroll Compressor |
| Quantity | – | 1 | |
| Fan Motor | Type | – | DC Inverter Axial Fan |
| Quantity | – | 1 | |
| Rated Output Power | kW per unit | 0.92 | |
| Noise | dB(A) | 50-60 | |
| Water-Side Heat Exchanger | Type | – | Double-Pipe |
| Water Flow | m³/h | 7.6 | |
| Unit Water Pressure Drop | kPa | 60 | |
| Unit Inlet/Outlet Pipe Connection Size | R1 1/2 | ||
| Dimensions (L×W×H) | mm | 1080×840×1670 | |
| Unit Operating Weight | kg | 259 | |
| Unit Gross Weight | kg | 254 | |
