Full inverter modular design enables rapid, energy-efficient hot water delivery, continuously meeting the 24/7 demand of four-person households.
| Model | Unit | MGH085 | |
| Moderate Temp Heating Capacity (A20℃) | Heating Capacity | kW | 85 |
| Input Power | kW | 18.89 | |
| COP | – | 4.50 | |
| Nominal Heating Capacity (A7℃) | Heating Capacity | kW | 65 |
| Input Power | kW | 15.85 | |
| COP | – | 4.10 | |
| Low Temp Heating Capacity (A-7℃) | Heating Capacity | kW | 44 |
| Input Power | kW | 11.66 | |
| COP | – | 3.80 | |
| Water Output under diffenrent temp | 20/7/-7℃ | L/h | 1830/1215/824 |
| Max Input Power | KW | 27.8 | |
| Max Input Current | A | 46.9 | |
| Power Supply | – | 380V/3N-/50Hz | |
| Heating Operating Ambient Temperature Range | ℃ | -35-45 | |
| Compressor | Type | – | DC Inverter Rotary Compressor |
| Quantity | – | 2 | |
| Fan Motor | Type | – | DC Inverter Axial Fan |
| Quantity | – | 4 | |
| Rated Output Power | kW per unit | 0.17 | |
| Noise | dB(A) | 52-62 | |
| Water-Side Heat Exchanger | Type | – | Double-Pipe |
| Water Flow | m³/h | 11.2 | |
| Unit Water Pressure Drop | kPa | 65 | |
| Unit Inlet/Outlet Pipe Connection Size | G2 Internal Thread | ||
| Dimensions (L×W×H) | mm | 1700×780×2160 | |
| Unit Operating Weight | kg | 415 | |
| Unit Gross Weight | kg | 410 | |
