Full inverter modular design enables rapid, energy-efficient hot water delivery, continuously meeting the 24/7 demand of four-person households.
| Model | Unit | MGH160 | |
| Moderate Temp Heating Capacity (A20℃) | Heating Capacity | kW | 200 |
| Input Power | kW | 49.3 | |
| COP | – | 4.06 | |
| Nominal Heating Capacity (A7℃) | Heating Capacity | kW | 160 |
| Input Power | kW | 43.2 | |
| COP | – | 3.70 | |
| Low Temp Heating Capacity (A-7℃) | Heating Capacity | kW | 82 |
| Input Power | kW | 23.91 | |
| COP | – | 3.43 | |
| Water Output under diffenrent temp | 20/7/-7℃ | L/h | 4300/2990/1530 |
| Max Input Power | KW | 69 | |
| Max Input Current | A | 124 | |
| Power Supply | – | 380V/3N-/50Hz | |
| Heating Operating Ambient Temperature Range | ℃ | -35-45 | |
| Compressor | Type | – | High Efficiency Scroll Compressor |
| Quantity | – | 2 | |
| Fan Motor | Type | – | Low Noise Axial Fan |
| Quantity | – | 2 | |
| Rated Output Power | kW per unit | 1.5 | |
| Noise | dB(A) | 62-70 | |
| Water-Side Heat Exchanger | Type | – | Double-Pipe |
| Water Flow | m³/h | 27.5 | |
| Unit Water Pressure Drop | kPa | 70 | |
| Unit Inlet/Outlet Pipe Connection Size | DN80 Clamp | ||
| Dimensions (L×W×H) | mm | 2100×1090×2250 | |
| Unit Operating Weight | kg | 1000 | |
| Unit Gross Weight | kg | 980 | |
