Featuring a space-saving single-fan design and full DC inverter technology with 10-layer quiet operation, it delivers a noise-free environment for tranquil comfort.
| Model | Unit | MC009EB | MC011EB | MC014EB | |
| Rated heating capacity | kW | 10 | 12 | 14.5 | |
| Rated Heating Input Power | kW | 2.77 | 3.34 | 4.19 | |
| Rated Heating COPh | 一 | 3.61 | 3.59 | 3.46 | |
| Nominal Heating Capacity | kW | 6.6 | 7.8 | 10 | |
| Nominal Heating Input Power | kW | 2.60 | 3.01 | 3.89 | |
| Nominal Heating COPh | – | 2.53 | 2.59 | 2.57 | |
| Low-Temperature Heating Capacity | kW | 5.4 | 6.4 | 8.2 | |
| Low-Temperature Heating Input Power | kW | 2.62 | 3.07 | 3.85 | |
| Low-Temperature Heating COPdh | – | 2.06 | 2.09 | 2.13 | |
| Nominal Cooling Capacity | kW | 9 | 11 | 13 | |
| Nominal Cooling Input Power | kW | 2.98 | 3.65 | 4.95 | |
| Nominal Cooling COPc | – | 3.02 | 3.01 | 2.63 | |
| IPLV(C) | 一 | 4.31 | 4.16 | 4.00 | |
| IPLV(H) | – | 3.18 | 3.31 | 3.18 | |
| Rated HSPF | – | 3.44 | 3.15 | 3.22 | |
| Rated APF | – | 3.47 | 3.23 | 3.24 | |
| Maximum Input Power | A | 5.3 | 5.50 | 6.80 | |
| Maximum Input Current | A | 24.1 | 25.0 | 30.9 | |
| Power Supply | – | 220V~/50Hz | |||
| Cooling Operating Ambient Temperature Range | ℃ | 10~48 | 10~48 | 10~48 | |
| Heating Operating Ambient Temperature Range | ℃ | -35-40 | -35-40 | -35-40 | |
| Compressor | Type | – | DC Inverter Rotary Compressor | ||
| Quantity | – | 1 | 1 | 1 | |
| Fan Motor | Type | – | DC Inverter Axial Fan | ||
| Quantity | – | 1 | 1 | 1 | |
| Rated output power | kw/unit | 0.1 | 0.1 | 0.17 | |
| Rated Power | Inverter Water Pump | kW | 0-0.095 | ||
| Fixed-Speed Water Pump | kW | 0.37 | 0.37 | 0.55 | |
| Water-Side Heat Exchanger | Type | – | Plate Heat Exchanger | ||
| Water flow | m3/h | 1.5 | 1.9 | 2.2 | |
| Unit Water Pressure Drop | kPa | 17 | 19 | 22 | |
| Unit External Head | Inverter Water Pump | m | 7 | 6 | 5 |
| Fixed-Speed Water Pump | m | 18 | 17 | 15 | |
| Unit Inlet/Outlet Pipe Connection Size | – | Rc1 | |||
| Design Maximum Inlet/Outlet Water Temperature Difference | ℃ | 7 | |||
| Dimensions (L×W×H) | mm | 998x395x1024 | |||
| Unit Operating Weight | kg | 102 | 107 | 110 | |
| Unit Gross Weight | kg | 100 | 105 | 108 | |
