Modular design enables flexible configurations, allowing series products to combine as interchangeable backup units.
| Model | Unit | MC065 DA4D3 | |
| Rated heating capacity | kW | 68 | |
| Rated Heating Input Power | kW | 20.7 | |
| Rated Heating COPh | – | 3.29 | |
| Nominal Heating Capacity | kW | 42.2 | |
| Nominal Heating Input Power | kW | 16.5 | |
| Nominal Heating COPh | – | 2.55 | |
| Nominal Cooling Capacity | kW | 65 | |
| Nominal Cooling Input Power | kW | 20.7 | |
| Nominal Cooling COPc | 一 | 3.14 | |
| Power Supply | 一 | 380V/3N~/50Hz | |
| Maximum Operation Power | kW | 29.2 | |
| Maximum Operation Current | A | 60 | |
| Cooling Operating Ambient Temperature Range | ℃ | 10-48 | |
| Heating Operating Ambient Temperature Range | ℃ | -15~30 | |
| Compressor | Type | 一 | High Efficiency Scroll Compressor |
| Quantity | – | 1 | |
| Fan | Type | – | Low Noise Axial Fan |
| Quantity | – | 1 | |
| Rated Power | kw/unit | 1.5 | |
| Water-Side Heat Exchanger | Type | 一 | Plate Heat Exchanger |
| Water flow | m/h | 11.2 | |
| Unit Water Pressure Drop | kPa | 31 | |
| Unit Inlet/Outlet Pipe Connection Size | – | Rc2 | |
| Design Maximum Inlet/Outlet Water Temperature Difference | C | 7 | |
| Dimensions (L×W×H) | mm | 1090x1050x2390 | |
| Unit Operating Weight | kg | 410 | |
| Unit Gross Weight | kg | 404 | |
