A single compact unit delivers cooling, heating, and hot water — enjoy cost-free hot water in summer and slash annual energy expenses by 50%.
| Model | MGC016EB4DSR3 | |
| Rated Heating Capacity(kw) | 20 | |
| Rated Heating Input Power(kW) | 6.1 | |
| Rated Heating COPh | 3.28 | |
| Nominal Heating Capacity(kW) | 13 | |
| Nominal Heating Input Power(kW) | 5.2 | |
| Nominal Heating COPh | 2.5 | |
| Low-Temperature Heating Capacity(kW) | 10.6 | |
| Low-Temperature Heating Input Power(kW) | 5.25 | |
| Low-Temperature Heating COPh | 2.02 | |
| Nominal Cooling Capacity(kW) | 16 | |
| Nominal Cooling Input Power(kW) | 6.1 | |
| Nominal Cooling COPc | 2.62 | |
| Heat Recovery Water Heating Capacity(kW) | 19 | |
| Water Output（L/H） | 400 | |
| Max Input Power(kW) | 9.1 | |
| Max Input Current(A) | 13.8 | |
| Power Supply | 380V/3N-/50Hz | |
| Cooling Operating Ambient Temperature Range (℃) | 10-48 | |
| Heating Operating Ambient Temperature Range(℃) | -35-40 | |
| Compressor | Type | DC Inverter Rotary Compressor |
| Quantity | 1 | |
| Fan Motor | Type | DC Inverter Axial Fan |
| Quantity | 2 | |
| Air-Side Water Pump Rated Power(W) | 550 | |
| Water-Side Heat Exchanger | Type | Plate Heat Exchanger |
| Water Flow(m³/h) | 2.8 | |
| Design Maximum Inlet/Outlet Water Temperature Difference(℃) | 7 | |
| Unit Operating Weight(kg) | 175 | |
| Unit Gross Weight(kg) | 170 | |
| Dimensions (L×W×H)（mm） | 998x395x1570 | |
